Zambia Copper Mine Top Hammer Drilling T38 Drill Coupling With Extension Drill Rod

1-5 PCS
MOQ
Negotiate
Cena £
Zambia Copper Mine Top Hammer Drilling T38 Drill Coupling With Extension Drill Rod
cechy Galeria opis produktu Poprosić o wycenę
cechy
specyfikacje
Name: Coupling Sleeve
Size: China T38 thread drill steel rod
Type: Carbide T38 Coupling Sleeves
Manufacturer: Sleeve Coupling Suppliers
Model No.: Coupling sleeve T38
Series: R32 T38 coupling sleeve
Threads: T38 thread coupling sleeve
Standard: T38 Coupling, Atlas Copco China,Coupling Sleeves
Specification: T45 rock drill coupling sleeve
Functions: T45 Thread Coupling Sleeves, Sleeve Coupling
Type No.: T45 steel drill coupling sleeve
Applications: For Connection T38 T45 T51 Extension Rods
Advantages: high quality and factory prices
High Light:

dth drilling tools

,

diamond core drilling bits

Podstawowe informacje
Miejsce pochodzenia: CHINA
Nazwa handlowa: ROSCHEN
Orzecznictwo: ISO
Numer modelu: T38
Zapłata
Szczegóły pakowania: Poly wooden box
Możliwość Supply: 1000000 pcs
opis produktu







Zambia Copper Mine Top Hammer Drilling T38 Drill Coupling With Extension Drill Rod







T38 Coupling with T38 Drill Rods Extension Rods for Zambia Copper Mine Top Hammer Drilling





Coupling Sleeve





Coupling sleeves, other name is Coupling, when using rock drills with male shank adapters and a conventional drifter rod, a coupling is required to join the adapter to the rod, ensuring the ends
touch for efficient energy transmission. Couplings are also used to connect several rods to each other in the same way. Couplings have a middle stop to prevent over-threading on to the drill rod.

We can manufactures semi-bridge, full bridge coupling sleeves for the percussive tools.



Semi-Bridge Coupling sleeve:


- Small non-threaded bridge in the center

- Steel cannot thread past bridge area

- Smaller diameter steel end portions fit together in the centre bridge area of the coupling

- Semi-bridged couplings are most suited to high torque machines

- Most rope and T threaded couplings are semi-bridged



Full-Bridge Coupling sleeve:


- Eliminates the potential for the coupling to creep along the threaded joints

- Typically used in surface applications

- Better uncoupling characteristics and tend to maintain tighter joints

- Less chance of jamming

- Best suited to machines equipped with independent rotation (i.e., S36IR rock drill)





Product features:

After special heat treatment, Roschen's Coupling sleeve ensuring the ends touch for efficient energy transmission, suitable for model powerful top hammers and drifter from Atlas Copco,
Halco, and Boat longyear etc.


Technical Specifications:

Zambia Copper Mine Top Hammer Drilling T38 Drill Coupling With Extension Drill Rod 0



How to order?


Style + Thread + Length +Diameter



Crossover adapter (MF adapter coupling)


T38F/R38M-260,T45F/T38M-260





Zambia Copper Mine Top Hammer Drilling T38 Drill Coupling With Extension Drill Rod 1

Full-bridge cross sectional view


Zambia Copper Mine Top Hammer Drilling T38 Drill Coupling With Extension Drill Rod 2
