Reaming Bit Pilot Adapter 6 12 Degree Taper R25 R28 R32 For Quarrying Ming

1-5pcs
MOQ
$1-9
Cena £
Reaming Bit Pilot Adapter 6 12 Degree Taper R25 R28 R32 For Quarrying Ming
cechy Galeria opis produktu Poprosić o wycenę
cechy
specyfikacje
High Light:

diamond core drilling bits

,

concrete core drill bit

Podstawowe informacje
Place of Origin: Germany
Nazwa handlowa: ROSCHEN
Orzecznictwo: CE, ISO
Model Number: R25 R28 R32
Zapłata
Packaging Details: Carton/Wooden box
Supply Ability: 200 pcs
opis produktu

Reaming bit and Pilot adapter 6 12 degree taper R25 R28 R32 For Quarrying Ming



Reaming drilling tools are used when a large diameter is needed to be reamed out after a pilot holes is drilled to a depth. We manufacture pilot reaming drilling tools, domed reaming button bits and adapter reaming button bits.


Pilot reaming drilling tools consist of pilot adapters and reaming button bits, however, both domed reaming button bits and and adapter reaming button bits are one-piece designed.


Thread sizes: R25, R28, R32
Reaming diameters: 76mm, 89mm, 102mm, 127mm


High Grade Tungsten Carbide Reaming Drill Bit R32 12 Degree



Description:

This type of bit is used for making large cut holes in drifting and tunneling. A smaller hole is first drilled and then reamed to the final size in combination with a pilot adapter.

1. Widely used in drifting and tunneling
2. R32 thread system
3. Color: Green, Blue or Based on Customer requirements
4. Material: Tungsten carbide and high strength alloy steel
5. Processing: CNC milling and proprietary heat treatment process
6. Type: R32 Reaming Bit 6°, 12°


Applications:

1. Underground mining
2. Tunneling

Competitive Advantage:
1. High grade tungsten carbide inserts
2. Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment.
