opis produktu



API Drill Pipe 2 3/8" to 6 5/8" OD Fatigue Resistance Drill Rods High Performance





API Drill Pipe 2 3/8" to 6 5/8" OD up to 48 feet in length for High Performance Fatigue Resistance Drill Rods


API Drill Pipe 2 3/8" to 6 5/8" OD up to 48 feet length for High Performance , Fatigue Resistance Drill Rods









ROSCHEN DRILL PIPE


Roschen manufactures the complete range of API drill pipe products from 2 3/8” OD to 6 5/8” OD in Range 2 and Range 3 sizes up to 48 feet in length.  In addition to standard API 5DP specifications, DP-Master also manufactures drill pipe in accordance with the following industry specifications:


1. NS-1
2. NOSRSOK
3. TH HILL
4. IRP 1.8 Sour Service
5. Customer Specific Specifications



API Drill Pipe 2 3/8" to 6 5/8" OD Fatigue Resistance Drill Rods High Performance 0



DESIGN


Roschen drill pipes are designed with long and smooth transition from upset to tube body to reduce the stress concentrations due to the transition from the upset ID to the drill pipe ID.

API Drill Pipe 2 3/8" to 6 5/8" OD Fatigue Resistance Drill Rods High Performance 1


All drill pipe and tool joints are manufactured in our modern and technologically advanced manufacturing facility at Roschen. Each tool joint is forged, machined, processed, inspected and tested by qualified operators to ensure the quality meets or exceed API specifications and customer’s requirements.


API Drill Pipe 2 3/8" to 6 5/8" OD Fatigue Resistance Drill Rods High Performance 2


FEATURES + OPTIONS:



In addition to the standard manufacturing processes where customer required, Roschen is able to perform hardbanding, internal coating, thread cold roll and make & break to the highest quality standard.



TOOL JOINT MAKE & BREAK


Factory make & break performed in controlled procedure ensure product consistency. This help to save valuable rig time and cost while reducing risk of mishandling incident and rig downtime.



SURFACE PROTECTION


Phosphate coating are applied to all threads and seal shoulders of connections to improve anti galling and corrosion.


Roschen can supply internal plastic coating according to customer requirements. The coating forms a protective layer in the pipe ID to prevent corrosion and thus extend the life span of the pipe in the drilling environment.



ENHANCED FATIGUE RESISTANCE


Cold rolling of thread roots has demonstrated the beneficial effects to improve fatigue resistance of the connections by minimizing crack initiation.



HIGH PERFORMANCE ROTARY SHOULDER CONNECTION


Roschen offers its RS-DS and RS-MT series double shoulder connections which outperform conventional API connections to meet the needs of deep, extended and challenging wells with greater torsional capacities.



INCREASE DRILL PIPE LIFE


Hardbanding on the tool joint or wear pad extends the service life of drill pipe. It can be applied in several configurations to suit clients’ requirements. Hardbanding is applied under closely controlled conditions resulting in a uniform, low porosity, wear resistant surface.


Roschen is authorised to apply market proven hardbanding products including ARNCO 100XT / 300XT, Tuboscope TCS8000 / TCSTI, Duraband NC, Tuffband NC and Castolin OTW 12.


Extra length tool joints can be incorporated into Roschen drill pipe to increase tong space to provide several recut to the connections.





Roschen has selected specially engineered metallurgy for its tool joints and tubes.  Tool Joints are manufactured from AISI 4137H steel with increased hardenability giving a very uniform microstructure and excellent mechanical properties through the cross section of the tool joint.


All Roschen Tubes are supplied by Tianjin Pipe Corporation (TPCO) which is a leadingglobal producer of seamless tubes with modern state-of-the-art facilities.  TPCO produces the Green Tubes according to Roschen’s chemistry and the tubes are then Austenitized, Quenched and Tempered in Roschen’s own Heat Treatment plant.  All mechanical testing is carried out in our own laboratory on site.


API Drill Pipe 2 3/8" to 6 5/8" OD Fatigue Resistance Drill Rods High Performance 3

ROSCHEN DRILL PIPE GRADES TABLE



SPECS. GRADE Yield Strength Tensile Strength ELONG
ATION
Hardness CHARPY NACE TOOL
JOINT
MIN MAX MIN MAX MAX Temp Minavg.Single
psi psi psi psi % HRC °F ft-lb ft-lb REQ'D % SYMS
DRILL PIPE GRADE MECHANICAL PROPERTIES
API 5RS  General
Use
E-75 75000  105000 100000  - API - room 40 35 no - API
X-95 95000  125000 105000  - API - room 40 35 no - API
G-105 105000  135000 115000  - API - room 40 35 no - API
5-135 135000  165000 145000  - API - room 40 35 no - API
Roschen
Series
Sour
Service
RS M-CY95 95000  110000  105000 130000 17 min 25 room 59 59 no - CY
RS M-CY105 105000  120000  115000 140000 17 min 28 room 59 59 no - CY
SS-95(IRP) 95000  110000  105000 130000 17 min 25 room 59 59 yes 85 ss
SS-105(IRP) 105000  120000  115000 140000 17 min 25 room 59 59 yes 85 ss
High
Strength
R-140 14000  160000  150000 - API - room 40 35 no - API
V-150 150000  165000  160000 - API - room 40 35 no - API
TOOL JOINT GRADE MECHANICAL PROPERTIES
API 5RS General
Use
API 120000 - 140000 - API - room 40 35 no - -
Roschen
Series
DS 130000 - 140000 - API - room 40 35 no - -
MT 130000 - 140000 - API - room 40 35 no - -
Sour
Service
CY 110000 125000 125000 145000 15 min 30 room 66 66 no - -
SS 110000 125000 125000 145000 15 min 30 room 66 66 yes 65 -



Charpy impact test at full size specimen
% SYMS as per NACE TM-01 77 test method A





ROSCHEN high-strength steel grades RS-140 and RS-150 are specially designed material grades to be used for applications that require higher strength in extreme drilling environments.


The high-strength steel grades are engineered with special chemistries and highly controlled manufacturing processes. These material can be manufactured to API standard sizes as well as customized configurations to meet different customer requirements.

API Drill Pipe 2 3/8" to 6 5/8" OD Fatigue Resistance Drill Rods High Performance 4


FEATURES:
• Engineered and tested for exceptional performance
• Strictly controlled manufacturing processes
• Substantial increase in tensile and torsional strengths
• Improved fatigue resistance
• Customisable configurations


Technical Parameters:

Grade Yield Strength(PSI)
Min
Ultimate Strength(PSI)
Min
Charpy Impact
(ft-Ibs) Average, 10x7.5 at -20°C
RS-140 140000 150000 59
RS-150 150000 160000 59
